A rimless back-to-wall toilet pan with soft-close seat cover.
A rimless back-to-wall toilet pan in glossy white vitreous china with a slim soft-close seat cover. Sized at 810 by 610mm with a 435mm pan height.
Size
810 x 610 x 435mm
Installation
Back-to-Wall
Material
Vitreous China
Finish
Gloss White
Quick check before ordering
Confirm S-trap or P-trap requirements and rough-in measurements before ordering.
Check set-out dimensions against your bathroom layout.
Confirm water inlet position - top or bottom left options are available.
Confirm compatible suite components before ordering.
Use a licensed plumber for installation.
What is included
| Not included | Cistern, inlet valve, flush button or actuator, pan connector, trap adapter and installation service are not included. |
|---|---|
| Best for | Bathrooms where a rimless back-to-wall toilet pan with a slim soft-close seat is required. |
Measure before you buy
- Confirm S-trap roughing-in between 160-350mm or P-trap roughing-in at 180mm matches your plumbing.
- Check the 810mm depth and 610mm width against available floor space.
- Confirm the inlet position - top left or bottom left or right - before ordering.
- Check clearance around the pan for the 435mm height and cistern requirements.
- Allow clearance above the pan for a cistern or maintenance access.
Complete specifications
| Product type | Back-to-Wall Toilet Pan |
|---|---|
| SKU | 50348 |
| Code | 50348 |
| Size | 810 x 610 x 435mm |
| Material | Vitreous China |
| Colour / finish | Gloss White |
| Mounting | Back-to-Wall |
| Barcode | 50348 |
Factory-direct confidence
MyDepot focuses on practical bathroom and home products with clear specifications and direct value. The goal is simple: make the renovation decision easier, not louder.
Care and installation notes
- Clean with a soft, damp cloth.
- Avoid abrasive cleaners and harsh chemicals.
- Wipe dry after cleaning.
FAQ
Does this listing include a cistern?
No. This listing is for the pan and seat cover only. Cistern, inlet valve and flush button must be selected separately as compatible suite components.
What S-trap and P-trap options are available?
The S-trap roughing-in range is 160-350mm depending on the connector selected. The P-trap roughing-in is 180mm. Confirm your rough-in before selecting connector components.
Specifications
| Color | Gloss White |
